BIOMASS  RING DIE PELLET MACHINE  (1500-2000 Kg/Hr)

  Revolutionize Your Biomass Production with the Cutting-Edge Ring Die Pellet Machine RE-1520.

Biomass Briquetting Machine for a Greener Tomorrow

Engineered to the exact specifications

800+ Satisfied Customers around the Globe

1,00,000+ Indirect Employment Generation

Eco-Conscious Choices, Fossil-Fuel Reprieve

Unearthing Energy, Protecting the Planet

Conserving Combustion, Cultivating Clean Energy

Our Pellet Machine is engineered for the efficient transformation of Biomass into high-density fuel. This unit offers versatile output, Ring Die Type Pellet Technology enables production of 06mm/08mm/10mm Pellets with cost effective way, leveraging a design that includes 06mm/08mm/10mm Pellet size in a Ring Die for precise forming.

Designed for maximum efficiency and performance, this heavy-duty pellet machine is your gateway to unlocking the full potential of sustainable biomass fuels. Whether you’re processing wood waste, crop residues, or chemical compounds, the RE-1520 delivers unparalleled results thanks to its innovative Ring die design and powerful 132kW motor.

  • Seamless Material Feeding due to the state of the art Upward Feeding design.
  • High yield Pelletizing due to the Dual-layer Die.

The Pelleting process typically involves several key steps: collection and preprocessing of raw materials, drying to reduce moisture content, hammering to achieve a powdery form, and finally, compressing the material under high pressure to form Pellets. The resulting Pellets are characterized by their high density, which enhances their combustion efficiency and makes them easier to transport and store.

Biomass Pellets serve as a renewable energy source, offering a viable alternative to fossil fuels. They can be used in various applications, including heating, cooking, and electricity generation. Additionally, the use of biomass pellets helps reduce greenhouse gas emissions and reliance on non-renewable energy sources, promoting environmental sustainability.

The market for biomass pellets is expanding, driven by increasing demand for clean energy solutions and the need for waste management strategies. As industries and households seek to reduce their carbon footprint, biomass pellets present an opportunity for both economic growth and environmental stewardship.

Pellet Specification
Pellet Diameter06mm / 08mm / 10mm
Pellet Length20 mm - 40 mm (Approximate)
Production Capacity1500-2000 Kgs/Hrs (Approximate) *
Raw- material sizePowdery Form / > 5mm
Moisture content of Raw Material10 % Max.
Required power connection187 HP (Approximate)
-Main Motor180 HP – 3 Phase
-Motor - Cooling System1 HP – 3 Phase
-Motor – Lubricating System3 HP – 3 Phase
-Motor – Dust Collector3 HP – 3 Phase
Practical used Amp. Load160 - 200 Amp (Approximate)
Power consumption60 - 90 Unit/MT (Approximate)
